The Dyness BF200-DC is a 215 kWh outdoor DC battery cabinet from the BF Series, designed for large commercial and industrial facilities looking to optimise their energy costs. Smart tariff scheduling allows the system to automatically charge during low-cost periods (solar peak or off-peak grid) and discharge during high-tariff hours, reducing electricity bills significantly. The IP55+C3 enclosure handles outdoor installation without any weather protection structure. Like other BF series cabinets, it connects on the DC bus of existing PV systems with no modification to the AC side. Air-cooling keeps internal temperatures in check. LFP cells with long cycle life and multi-layer safety protection.
Technical Specifications
| Type | battery |
| Model | BF200-DC |
| Size | 215 |
| Warranty | 10 years product warranty |
| Category | BF Series |
| Full Specifications | |
| Battery Type | LFP (LiFePO4) |
| Cell Capacity | 280Ah |
| Pack Config | 1P16S×15 |
| Rated Current A | 140 |
| Max Current A | 160 |
| Voltage Range Dc | 696–864Vdc |
| Nominal Capacity | 215kWh |
| Pv Max Input Power | 50kW×3 |
| Pv Input Voltage Range | 200–670Vdc |
| Pv Start Up Voltage | 250Vdc |
| Pv Mppt Paths | 3 |
| Dc Rated Output Power | 25kW×2 |
| Dc Output Voltage | 700±20Vdc |
| Dc Max Output Current | 50A×2 |
| Weight Kg | 2500 |
| Dimensions Wdh Mm | 1850×1195×2258 |
| Max Efficiency Pct | 94 |
| Cooling | Air-cooling |
| Ip Rating | IP55 |
| Anti Corrosion | C3 |
| Operating Temp | -20~50°C (derating above 45°C) |
| Noise Db | ≤75 |
| Comms | Ethernet/4G/RS485 |
| Certification | CE |
